Sliding system with thermal barrier SMARTIA S350
Description
The SMARTIA S350 is a modern and flexible sliding system with a flat design and thermal barrier. It is ideal for refurbishment and rehabilitation, due to its ease of construction manufacturing.
Benefits
-
Very good value for money
-
Energetic efficiency
-
Easy access and high degree of functionality
-
Increase the volume of natural light
-
High noise attenuation
-
Modern design
-
High quality with certified performances
Generic
TYPES OF WINDOWS
Sliding
TYPE OF WINDOW
Double
THERMAL INSULATION
Yes
EXTERIOR FORMS
Rounded, Right
Technical
WIDTH OF ALUMINUM VISIBLE IN THE CENTRAL AREA (OF THE INVERSOR)
102 mm
MECHANISM
Perimeter closing mechanism
VISIBLE ALUMINUM WIDTH IN THE CENTER SUPPORT AREA (JOINT PROFILE)
50 mm
SEALING METHOD
Permietral continuous with 2 levels of fine tri brushes
MAXIMUM THICKNESS OF THE WINDOW
up to 25 mm
TYPE OF THERMAL INSULATION
24 mm polyamide, PVC parts
Performance
SEALING IN WATER
6Α
RESISTANCE TO WIND LOADING
C2/B3
PERMEABILITY AT AIR
Class 4
PHONIC INSULATION
28 dB
Characteristics
CASEMENT DEPTH
35 mm
TYPOLOGIES
Slides on one, two or three treads Slides located on the same tread, with head-to-head closure Slides on the same tread with the possibility of wall mounting
MINIMUM VISUAL ALUMINUM HEIGHT
71 mm
CASEMENT WEIGHT
up to 180 Kg
.
TYPOLOGIES
All available typologies
Sliding window / door with two movable doors
Window / door in three movable sheets
Window / Sliding door in four movable doors, closing head to head
Sliding window / door in two movable sheets, equipped with insect screen
Window / sliding door with four movable doors, closed at the end, equipped with insect nets
Window / sliding door in two movable sheets, equipped with aluminum roll and mesh
Sliding window / door in a movable sash, retractable in the wall, equipped with shutters
Window / sliding door in a movable leaf, retractable in the wall, equipped with mesh and oblong mesh
Window / sliding door in two movable retractable wall panels, equipped with insect screen and shutters
Window / sliding door in a movable sash, retractable in the wall, equipped with insect screen and aluminum roll
Window / Sliding door in two movable doors, with fixed overhead light
Window / Sliding door in two movable doors and fixed side doors
